Description
3003 aluminum foil overview
Aluminum foil 3003 is the most widely used alloy in the 3000 series. 3003 alloy aluminum foil adds metallic manganese to improve the physical properties of the aluminum foil. It is also known as the “Al-Mn” series metal and has a series of remarkable properties and a wide range of applications.
3003 aluminum alloy foil material properties
3003 aluminum foil is mainly composed of aluminum, manganese and other elements. The addition of manganese element significantly improves its strength and corrosion resistance. 3003 aluminum foil is about 10% stronger than 1100, but the overall strength is not high (slightly higher than 1000 series industrial pure aluminum). At the same time, it has excellent anti-rust properties. Its corrosion resistance is very good, close to the corrosion resistance of industrial pure aluminum. It has good corrosion resistance to the atmosphere, fresh water, sea water, food, organic acids, gasoline, neutral inorganic salt water solutions, etc. The corrosion resistance in dilute acid is also very good.
Aluminum foil 3003 element composition
| Aluminum foil 3003 chemical element content (%) | ||||||||
| Element | Al | Mn | Cu | Fe | Si | Zn | Each | Total |
| Composition (%) | 96.7-99 | 1.0-1.5 | 0.05-0.20 | 0.7 | 0.6 | 0.10 | 0.05 | 0.15 |
3003 aluminum foil mechanical properties
Here is a table listing the typical mechanical properties of 3003 aluminum foil:
| Property | Value | Notes |
|---|---|---|
| Tensile Strength | 130 – 170 MPa | Varies depending on temper and thickness |
| Yield Strength | ~115 MPa | Varies depending on temper and thickness |
| Elongation | 1 – 8% | Varies depending on thickness and temper |
| Hardness | ~40 HB (Brinell Hardness) | Varies depending on temper |
Temper-Specific Properties
Annealed (O Temper)
| Property | Value |
|---|---|
| Tensile Strength | ~130 MPa |
| Yield Strength | ~70 MPa |
| Elongation | ~8% |
Half Hard (H14 Temper)
| Property | Value |
|---|---|
| Tensile Strength | 150 – 165 MPa |
| Yield Strength | 125 – 140 MPa |
| Elongation | 1 – 4% |
Full Hard (H18 Temper)
| Property | Value |
|---|---|
| Tensile Strength | 165 – 170 MPa |
| Yield Strength | 140 – 150 MPa |
| Elongation | ~1% |
